CU199iN CU Model Series

View Energy Guide

Commercial condensing tankless water heater CU199iN from Rinnai is precision engineered to provide endless hot water for the most demanding of applications such as restaurants, hospitality, education institutions, multifamily residential buildings and more. CU199iN is designed for indoor installation, natural gas fuel, is WiFi ready to monitor performance across multiple units to ensure up time is maintained. Multiple venting options offer installation flexibility to meet your existing layout or for new build optimization.

97% Thermal Efficiency
15,000 BTU (minimum)
199,000 BTU (maximum)
Warranty

View Rebates & Offers

: Commercial condensing tankless water heater CU199iN from Rinnai is precision engineered to provide endless hot water for the most demanding of applications such as restaurants, hospitality, education institutions, multifamily residential buildings and more. CU199iN is designed for indoor installation, natural gas fuel, is WiFi ready to monitor performance across multiple units to ensure up time is maintained. Multiple venting options offer installation flexibility to meet your existing layout or for new build optimization.
: Supply Connections

Connection Connection Size

Gas 3/4" MNPT / (19 mm)

Cold Inlet 3/4" MNPT / (19 mm)

Hot Outlet 3/4" MNPT / (19 mm)

Condensate Drain 1/2" NPT / (13 mm)
: Product Depth 11.45 in / (290 mm)

Product Height 31.3 in / (795 mm)

Product Width 18.5 in / (470 mm)

Product Weight 64 lb / (29 kg)

Gas Type Natural Gas

Recirculation Capable Yes

Domestic Hot Water Flow Rate (Maximum) 11 GPM / (41.6 l/min)

Wi-Fi Capable Yes

SCAQMD Approved Ultra Low NOx

Warranty information is available in the Installation & Owner Manual.
